C1C-B 2MP Smart Home Camera

Specifications

Model CS-C1C-B (1080P)
Version E0-1E2WF
Camera

Image Sensor 1/3" Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 2.8 mm, view angle: 108° (Diagonal), 91° (Horizontal), 50° (Vertical)
Minimum Illumination 0.5 Lux @(F2.2, AGC ON), 0 Lux with IR
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
Night Vision 12 m

Video & Audio

Max. Resolution 1920 × 1080
Frame Rate Max: 25 fps; Self-Adaptive during network transmission
Video Compression H.265
H.265 Type Main Profile
Video Bit Rate Full HD; Hi-Def; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Max. Bitrate 1 Mbps
Function
Smart Alert Motion detection
Two-way Talk Supports
General Function Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection,
Watermark
Network
Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ cloud proprietary protocol
Storage
Local Storage MicroSD card slot (Max. 256 GB)
Cloud Storage EZVIZ Cloud Storage
General
Operating Conditions -10 oC ~ 45 oC (14 °F ~ 113 °F ), Humidity 95% or less (non-condensing)
Power Supply DC 5V / 1A
Power Consumption MAX. 3.0 W
Dimensions 63 × 63 × 103 mm (2.48 × 2.48 × 4.06 inch)
Packaging Dimensions 91.5 × 87.5 × 149 mm (3.60 × 3.44 × 5.87 inch)
Net Weight 83 g (2.93 oz)
Weight (With Package) 310 g (10.93 oz)
In the box

In the box - C1C-B Camera
- USB Cable
- 3-Meter Power Adapter
- Foam Sticker
- Metal Plate
- Regulatory Information
- Quick Start Guide
